Sheridan Wagon Wheel Ceiling Fan

KV52SHR-BRZ – 52″
A: Fan blade to ceiling: 27.25″
B: Downrod – 4.5″ (Required to install fan)
D: Blade Diameter – 52″
H: Height – 28.25″ from bottom of fan to ceiling

Downrod Outer Diameter: 0.75″ (Both ends threaded)
Wagon Wheel Diameter: 30″
Ceiling Canopy Diameter: 6.5″
Assembled in USA from American and Imported Components
Lifetime Motor Warranty and 1 Year Unconditional on Everything Else
3 Speed Reversible
Included Pull Chains (Remote package eliminates pull chains)
Accent Lighting inside Motor Housing
Blade Pitch: 14°
Weight: 38 Lbs
Motor: 188mm x 20mm Heavy Duty Motor
Bulbs: 4-25W candelabra bulbs max. (included)
UL Rated for Indoor Location Use
Max. Ceiling Slope: 30° (45° with adapter)
Shipping Weight: 43 Lbs
Container: 25″ x 15″ x 13″
Airflow: 6700 CFM
Airflow Efficiency: 63 CFM per watt

KV60SHR-BRZ – 56″ and 60″
A: Fan blade to ceiling: 27.25″
B: Downrod – 4.5″ (Required to install fan)
D: Blade Diameter – 56″ or 60″
H: Height – 15.5″ from bottom of fan to ceiling
Downrod Outer Diameter: 0.75″ (Both ends threaded)
Wagon Wheel Diameter: 42″
Ceiling Canopy Diameter: 6.5″
Assembled in USA from American and Imported Components
Lifetime Motor Warranty and 1 Year Unconditional on Everything Else
3 Speed Reversible
Included Pull Chains (Remote package eliminates pull chains)
Accent Lighting inside Motor Housing
Blade Pitch: 14°
Weight: 40 Lbs
Motor: 188mm x 25mm Heavy Duty Motor
Bulbs: 4-25W candelabra bulbs max. (included)
UL Rated for Indoor Location Use
Max. Ceiling Slope: 30° (45° with adapter)
Shipping Weight: 45 Lbs
Container: 25″ x 15″ x 13″
Airflow: 7800 CFM
Airflow Efficiency: 62 CFM per watt
